Double Cone Collets
Advantages:
- Clamping range +0,2 mm up to -0,8 mm
- Chip cover cap if technically possible, depends on type and ø
- This Alloy is not heat sensitive and very hard – non-abrasive
- High runout accuracy
- Prevents cold shut and friction between Material and guide bush
- Square and hexagon profiles are also available
- Special profiles according to you drawing can be eroded
- Suitable for all pneumatic guide-bush-systems
- Also available in grey cast iron and nitrided steel.
Chip Cover Cap Mounting
Double Cone Collets Options
Kroko slots prevents chips and dirt from getting into the bores and the slots, as well as all the advantages of the regular double cone collets.
Advantages:
- High durability
- Excellent runout
- Will not disturb finish of picked part
Advantages:
- Insert made out of Brass or Plastic provides additional material guidance in the collet.
- Length and ID of the insert is made to customers specification.
- Insert is delivered already pressed into collet.
When ordering please specify: material, length and ID of the insert.
Advantages:
- Easy & quick fitting
- Suitable for 3 or 4 slot collets
- Disks can be turned to any specific diameter
- Prevents breakage of stepped collets
JBS part number converter
Use our online converter tool to convert JBS Double Cone collet part number to iSwiss Double Cone collet part number.
Just enter JBS 6-digit part number in the field and click the “Convert” button.
Special Double Cone Collets
Please specify size and type of the dead length collet you need, submit the form, and we will get back to you soon with a quote.
